Max Safe Working Load: |
Metric |
Imperial |
Polyester | 400kg | 882 lbs |
Spacer | 300kg | 661lbs |
Parachute | 200kg | 441lbs |
Mesh | 300kg | 661lbs |
Available Sizes (mm): |
A |
B |
C |
D |
Small (S) | 480-560mm | 500mm | 520mm | 310mm |
Medium (M) | 600-700mm | 550mm | 580mm | 410mm |
Large (L) | 740-820mm | 670mm | 640mm | 410mm |
Extra Large (XL) | 800-900mm | 710mm | 670mm | 410mm |
Pro Tip: For most accurate results measure B + C together, then keeping the tape in the same place measure just B and subtract it from the total to give the value of C
Suitability in Use: |
|
Loops lifters (L) | No |
Clips lifters (C) | Yes |
Amputees above the knee | No |
Bilateral below the knee amputees | Yes |
Limited head and neck control | Yes |
In-situ/All day use (Parachute/Spacer fabric) | Yes |
Toileting use | No |
Transfer Types: |
|
Transfers from supine | Yes |
Transfers to supine | Yes |
Transfers from seated | Yes |
Transfers to seated | Yes |
Transfers from floor (semi-recumbent)* | Yes |
*With suitable hoisting equipment
