Metric |
Imperial
|
|
Height Range (floor to top of mattress platform) |
110-735mm | 4¼-29” |
External Length | 2120mm |
83½" |
External Width 3ft/90cm Single 3ft6/105cm Wide Single 4ft/120cm Small Double |
1020mm 1170mm 1320mm |
40¼" 46” 52” |
External Height (in lowest position) |
880mm | 34¾" |
External Height (in highest position) |
1490mm |
58¾" |
Mattress Platform Length |
2000mm | 78¾” |
Mattress Platform Width 3ft/90cm Single 3ft6/105cm Wide Single 4ft/120cm Small Double |
900mm 1050mm 1200mm |
35½” 41½" 47¼" |
Maximum User Weight 3ft/90cm Single 3ft6/105cm Wide Single and 4ft/120cm Small Double |
165kg 215kg |
26st 33¾st |
Safe Working Load 3ft/90cm Single 3ft6/105cm Wide Single and 4ft/120cm Small Double |
200kg 250kg |
31½st 39¼st |
Back Rest Length | 880mm | 34¾” |
Thigh Rest Length | 330mm | 13” |
Calf/Foot Rest Length | 530mm | 21” |
Integrated Length Extension | +200mm | 8" |
Maximum Back Rest Angle | 70º | |
Maximum Leg Rest Angle | 39º | |
Power Cord Length | 2100mm | 82¾” |
Hoist Clearance | Unrestricted | |
4 Braked Twin Castors | 2 x 70mm | 2 x 2¾" |
Medical Device Class (Under MDD 93/42 EEC) | Class I | |
Degree of Protection to DIN EN 60601-2 | Type B | |
Warranty | 3 years parts and labour (+2 years optional extension) |
